Ashoka Foam Group was Established in 1987. Alutuff brand is a leading manufacturer and exporter of Aluminium Composite Panels, Aluminium Composite Wall Panels and Aluminium Composite Roof Panels. We have world class and advanced level of super wide aluminium panels, widely used for construction of residential and commercial buildings. We are specialized in manufacturing of weather resistance and fire proof aluminium panels, with more than 10 years of development, we have established trusted business relationships with customers in India and worldwide. We can also customise requirements, so we warmly welcome customised product orders according to clients. Alutuff has wide usage as panel applies in Balcony and Canopy Cladding, Bank & Institutions, Columns Covers and Beam Wraps, Commercial and Public Signs, Corporate Identity, Display Boards, Malls, Multiplexes, Showroom Finishes, Spanderal and Canopy Panels.
Alutuff is leading and one of the largest manufacturers of Aluminium Composite Panel in India. We play a very important and vital role in introduction of new ranges at regular intervals and focus on those products which can be the best and enthuse our customers. It's through our commitment to our product quality, Alutuff ACP/HPL is a high quality construction product available in large variety with innovative ideas, an eye catching appeal. It's offers unmatched, aesthetics, styles and durability...
| Description | Specification |
|---|---|
| Aluminium Tube(Black Powder Coated) | 25 x 38 x 1.6 mm |
| Aluminium Angle(Cleast) | 19 x 19 x 2 mm |
| Screw(Powder Coated) | SS 25" (Star Headed) |
| NAME | 3MM(0.25mm) | |
|---|---|---|
| S.No. | TEST CONDUCTED | ALUTUFF |
| 1 | Panel Weight | 3.87Kg/m2 |
| 2 | Gravity | 1.42g/cc |
| 3 | Panel Thickness | 2.99~3.00mm |
| 4 | F.D.F.T. | 30~31 µm |
| 5 | B.D.F.T | 14~15 µm |
| 6 | Coating Type | PVDF |
| 7 | Specular Gloss (F) | 25~26 % |
| 8 | Pencil Hardness | 2H |
| 9 | Cross Hatch Test | No Peeling Found |
| 10 | Impact Resistance | No Cracking found |
| 11 | Acid Resistance | No Effect |
| 12 | Protective Weight | 0.085 Kg/m2 |
| 13 | LDPE (Quality) | 0.700 Gram/10min |
| 14 | 0.967 G/cc | |
| 15 | -X Batch | |
| 16 | Coil Thickness (F) | 0.25mm |
| 17 | Coil Thickness (B) | 0.25mm |
| 18 | Bonding Strength | 6 N/mm |
| 19 | Tensile Strength | 20 N/mm2 |
| 20 | Elongation | 7.00% |
| NAME | 3MM(0.25mm) | |
|---|---|---|
| S.No. | TEST CONDUCTED | ALUTUFF |
| 1 | Panel Weight | 5.68Kg/m2 |
| 2 | Gravity | 1.42g/cc |
| 3 | Panel Thickness | 3.95~3.98 mm |
| 4 | F.D.F.T. | 30~31 µm |
| 5 | B.D.F.T | 14~15 µm |
| 6 | Coating Type | PVDF |
| 7 | Specular Gloss (F) | 25~26 % |
| 8 | Pencil Hardness | 2H |
| 9 | Cross Hatch Test | No Peeling found |
| 10 | Impact Resistance | No Cracking found |
| 11 | Acid Resistance | No Effect |
| 12 | Protective Weight | 0.085 Kg/m2 |
| 13 | LDPE (Quality) | 0.700 Gram/10min |
| 14 | 0.967 G/cc | |
| 15 | -X Batch | |
| 16 | Coil Thickness (F) | 0.50mm |
| 17 | Coil Thickness (B) | 0.50mm |
| 18 | Bonding Strength | 11.1 N/mm |
| 19 | Tensile Strength | 45 N/mm2 |
| 20 | Elongation | 7.00% |
Fire-retardant (FR) materials have become an ingredient in modern construction. With more and more skyscrapers towering towards the skies in bustling cities, fire protection has taken center stage across the world. Using Genuine FR material is critical to safety in the Fire Rated Construction System.
A typical ACP-cladded facade in India has a frame structure comprising a non-load-bearing brick wall followed by plaster, steel frame and an ACP envelope fixed on the frame As an important criterion for resistance to fire, the ACP envelope should contain fire and retain its structural integrity up to 2 hours. But that's not the only feature that contributes to fire protection. An authentic rating for resistance to fire also takes into account that smoke kills faster than fire, among other vital factors. This is where Alutuff FR ACP- Fireshield stands above the rest.
Fireshield is a non halogenated FR material that produces water vapour when ts heat up. It does hot produce toxic gases like the halogenated materials. Magnesium Hydroxide MDH is the nor-halogenated material that s mixed with PE to form the core of Alutuff FR products. MDH has a better fire resistance performance than Aluminium Trihydrate (ATH). Transformation from solid to plastic (the pont of ignition up to 360 by releasing water molecules and bringing down the temperature continuously.
| Core Details | Polyethylene | Magnesiun Hydroxide(MDH) | Aluminium Trihydrate |
|---|---|---|---|
| Chemical Reaction | CH2 + O2 = CO2 + H2O | Mg(OH)2 = MgO + H2O | 2Al(OH)3 = A1203 + 3H20 |
| Decomposition temperature | 900C to 1100C | 3100C to 3600C | 1900C to 2400C |
| Status | Generation | Heat absorption | Heat absorption |
Alutuff the end-to-end production facility is fireproof and completes with global standards. The one production unit, spread over 25,000 sqm at Bareilly, is equipped with up-to-date technology and testing facilities. The stringent quality control system keeps a sharp eye on each and every unit process.
To ensure there is no damage to the edges or surface of the high-end material (Facia, HPL panels), please handle them with extreme care. During the process of transporting the panels, they should be protected well against slipping. Make sure that the panels are lifted securely while handling or unloading them. Kindly avoid pulling or pushing them over the edge. It's important to remove the protective film within 45 day of installation. The panels must be stocked parallel to the ground on flat and stable supporting panels. They should be in completely flat position. Erroneously storing the panels can lead to permanent damage or deformation.
Alutuff Fireshield having more than 71% mineral content and made with AA5005/AA3105 alloy, is a tried and tested non-halogenated FR ACP which :
